TRENDnet 450Mbps Wireless N Gigabit Router TEW-691GR Overview, Specs



TRENDnet's 450Mbps Wireless N Gigabit Router, model TEW-691GR, redefines wireless router performance. This router's raw horsepower seamlessly streams HD movies to your entertainment center, transfers content from countless users, and generates record wireless coverage.

Gigabit Wide Area Network and Local Area Network ports transfer wired data fast. Embedded GREENnet technology reduces power consumption.

Advanced Multiple Input Multiple Output (MIMO) antenna technology with three spatial streams per antenna generates a maximum theoretical wireless throughput of 450Mbps. Wi-Fi Protected Setup (WPS) integrates other WPS supported wireless adapters at the touch of a button. The latest in wireless encryption and a secure firewall protect your digital network. WMM® Quality of Service (QoS) technology prioritizes gaming, Internet calls, and video streams. LEDs on the front of the router convey device status.

Hardware
Standards
  • Wired: IEEE 802.3 (10Base-T), IEEE 802.3u (100Base-TX), IEEE 802.3ab (1000Base-T)
  • Wireless: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
LAN4 x 10/100/1000Mbps Auto-MDIX port
WAN1 x 10/100/1000Mbps Auto-MDIX port
WPS ButtonWi-Fi Protected Setup (WPS) connects with other WPS compliant devices
WDSEnable/disable Wireless Distribution System support
LED IndicatorPower, WLAN, LAN, WPS
Power Adapter12V DC, 1A external power adapter
Power Consumption450mA (max.)
Dimension (L x W x H)148x 180 x 32mm (6.2 x 7.1 x 1.0in.)
Weight289g (10 oz)
TemperatureOperation: 0°~ 40°C (32°F~ 104°F)
Storage: -20°~ 60°C (-4°F~140 °F)
HumidityMax. 90% (non-condensing)
CertificationsCE, FCC
Wireless
Frequency2.412 ~ 2.472 GHz
Antenna3 x 4dBi fixed dipole antennas
ModulationOFDM: BPSK, QPSK, 16-QAM, 64-QAM
DBPSK, DQPSK, CCK
Data Rate
  • 802.11b: up to 11Mbps
  • 802.11g: up to 54Mbps
  • 802.11n: up to 450Mbps
Security64/128-bit WEP, WPA/WPA2-PSK, WPA/WPA2-RADIUS
Multiple SSID
Output Power
  • 802.11b: 11dBm (typical)
  • 802.11g: 15dBm (typical) 802.11n: 15dBm (typical)
Receiving Sensitivity
  • 802.11b: -84dBm (typical)
  • 802.11g: -72dBm (typical)
  • 802.11n: -69dBm (typical)
Channels2.4GHz : 1~11 (FCC), 1~13 (ETSI)
