The 300Mbps Wireless N Gigabit Router offers unsurpassed wireless speed, coverage and reliability. Enjoy up to 14x the speed and 6x the coverage of a wireless g connection*.
Gigabit Wide Area Network and Local Area Network ports transfer your data fast. Wi-Fi certification ensures optimal wireless throughput signal strength and compatibility.
Advanced Multiple Input Multiple Output (MIMO) antenna technology eliminates wireless dead spots. Wireless encryption and a manual on/off wireless switch keeps your data safe. Wireless Protected Setup (WPS) integrates other WPS supported wireless adapters at the touch of a button. Seamlessly stream HD media, download files, surf and play games at wireless n speeds.
*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and coverage will vary depending on interference, network traffic, building materials and other conditions.
| Hardware | | Standards | - Wired: IEEE 802.3 (10Base-T), IEEE 802.3u (100Base-TX) and IEEE 802.3ab (1000BaseT)
- Wireless: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
| | WAN | 1 x 10/100/1000Mbps Auto-MDIX port (Internet) | | LAN | 4 x 10/100/1000Mbps Auto-MDIX port | | Wireless On/Off Switch | Turn on/off wireless LAN | | WPS Button | Wi-Fi Protected Setup (WPS) automated wireless connection push button | | Reset Button | Reset Router to Factory Defaults | | Connection Type | Dynamic IP, Static (fixed) IP, PPPoE, PPTP, L2TP | | NAT Firewall | 3K configurable NAT entries; restricted NAPT
IP ranges, port ranges and schedule
Port triggering for 24 special applications
ALG support (enable/disable support) –RTP/RTSP, AOL, FTP, ICMP, WMP/MMS, NetMeeting, SIP | | WDS | Enable/disable Wireless Distribution System support | | UPnP | UPnP IGD 1.0 compliant | | DMZ | DMZ host, 24 configurable Virtual Servers and Game Servers | | DNS | Static or WAN assigned DNS servers; 4 verified services for DDNS | | Internet Access Control | Time based Internet access; port range/service filtering; Internet domain restriction; 32 user defined schedules, 24 MAC address filter entries | | LED Indicator | Power, LAN1~LAN4, WAN, WLAN, WPS | | Power Switch | On/Off power switch | | Power Adapter | 12V DC, 1A external power adapter | | Power Consumption | 779mA | Dimension
(L x W x H) | 150 x 163 x 26 mm (5.9 x 6.4 x 1.0 in) | | Weight | 350g (0.8 lb) | | Temperature | - Operation: 0°~ 40°C (32°F~ 104°F)
- Storage: -20°~ 60°C (-4°F~140 °F)
| | Humidity | Max. 90% (non-condensing) | | Certifications | CE, FCC | | Wireless | | Frequency | 2.412 ~ 2.472 GHz | | Antenna | 3 x 4dBi fixed dipole antenna | | Modulation | DBPSK/DQPSK/CCK/OFDM (BPSK/QPSK/16-QAM/64-QAM) | | Data Rate | - 802.11b: up to 11Mbps
- 802.11g: up to 54Mbps
- 802.11n: up to 300Mbps
| | Security | - WEP(HEX/ASCII): 64/128-bit
- WPA(AES/TKIP): WPA/WPA2-Radius, WPA-PSK/WPA2-PSK
| | Output Power | - 802.11b: 18dBm (typical)
- 802.11g: 15dBm (typical) 802.11n: 12dBm (typical)
| | Receiving Sensitivity | - 802.11b: -84dBm (typical) @ 11Mbps
- 802.11g: -72dBm (typical) @ 54 Mbps
- 802.11n: -65dBm (typical) @ 300Mbps
| | Channels | 1~ 11 (FCC), 1~13 (ETSI) |  |
|
