TRENDnet Wireless 3-Port Print Server TEW-P21G Overview, Tech Specs



TRENDnet TEW-P21G is a wireless print server that transforms virtually any stand-alone USB or Parallel networkable printer into a shared network printer. The TEW-P21G is compatible with IEEE 802.11g 54Mbps network and it has two USB 2.0 and one Parallel printer port. Network professionals can easily manage the print server using Web Browser and utilize the TEW-P21 to promote productivity in a workgroup environment with low equipment cost.

Hardware
Standards
  • Wired: IEEE 802.3 10Base-T, IEEE 802.3u100Base-TX
  • Wireless: IEEE 802.11b/g
Printer Interface
  • 1x Parallel DB25 (Female) Port
  • 2 x USB 2.0, 1.1 Compliant USB Type A Port
LAN Port10/100Mbps Auto-Negotiation UTP/STP RJ-45Port
CPU/ SDRAM / Flash ROMRDC R2880 100MHz / 8MByte / 2MByte
LEDPower, Link/Act, WLAN, USB1, USB2, LPT
Transport ProtocolTCP/IP, SMB, NetBEUI, AppleTalk
TCP/IP Protocol SupportedBOOTP, SNMP, Telnet, TFTP, FTP, LPD, RARP, DHCP,IPP
OS Support
  • Windows 7(32/64-bit)/Vista(32/64-bit)/2003 Sever/XP(32/64-bit)/2000/NT/ME/98(SE)
  • Netware 5.x NDPS LPR Remote Printing (TCP/IP)
  • HP-UX Unix, Sun OS, Solaris, SCO Unix, AIX
  • Unixware, Linux & Mac OS 10.1~10.6
ManagementPS Wizard, PS Utility, PS Monitor or Web-Browser Configuration
Power5V DC 2.5A External Power Adapter
Dimensions206 x 122 x 34mm (8.1 x 4.8 x 1.3 in.) Not including antenna
Weight310g (11oz.)
Temperature
  • Operating: 0°~50°C (32°~122°F)
  • Storage:-25°~55°C (-13°~131°F)
Humidity10%~90%(non-condensing)
CertificationCE, FCC
Wireless
Frequency2.4 ~ 2.4835 GHz (Industrial Scientific Medical Band)
Module Technique
  • 802.11b: CCK (11 and 5Mbps), DQPSK (2Mbps),DBPSK (1Mbps)
  • 802.11g: OFDN
Encryption64/128-Bit WEP, WPA-PSK, WPA2-PSK(TKIP/AES)
Antenna2dBi Detached Diversity Antenna (Reverse SMA Connector)

Data Rates

  • IEEE 802.11g: 54Mbps, 48Mbps, 36Mbps,24Mbps, 18Mbps, 12Mbps, 9Mbps and 6Mbps
  • IEEE 802.11b: 11Mbps, 5.5Mbps, 2Mbps and1Mbps (Auto Fallback)
Channel1~11 Channels (FCC), 1~13 Channels (ETSI)
