TRENDnet 150Mbps Mobile Wireless N Router TEW-655BR3G Overview, Specs



The 150Mbps Mobile Wireless N Router (model TEW-655BR3G) connects to the Internet either using a traditional hard wired connection or by cutting the cables and connecting with a compatible wireless mobile USB dongle from a 3G* Internet service provider such as AT&T™, Sprint™, T-Mobile™, or Verizon™**.

Designed for true portability the router has a rechargeable and replaceable 2.5 hour lithium ion battery. Compatible with USB dongles from every mobile provider, this compact router connects to the Internet anywhere there is a 3G* mobile connection.

No installation is required, simply plug the 3G* USB adapter into the router to share a single Internet connection. The latest wireless encryption protects your valuable data. Wi-Fi Protected Setup (WPS) integrates other WPS supported clients at the touch of a button. An on/off switch on the back of the devices saves battery life. For long trips, power the router with TRENDnet's Car Adapter, model TA-CC.


*List of compatible 3G USB modems

**Must have an active Internet plan with the respective third party mobile provider

***Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and coverage will vary depending on interference, network traffic, building materials, and other conditions.

Hardware
Standards
  • Wired: IEEE 802.3 (10Base-T), IEEE 802.3u (100Base-TX)
  • Wireless: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n based on IEEE 802.11n (draft 2.0) technology
  • USB: USB 2.0, USB 1.1
USB Port1 x USB 2.0 port for 3G* USB adapter (Internet)
Ethernet Port1 x 10/100Mbps Auto-MDIX port (LAN/Internet WAN)
WAN Connection TypeEthernet: Dynamic IP, Static IP, PPPoE, L2TP, PPtP USB: 3G, 3.75G
Compatible Mobile NetworksUMTS/HSPA, WCDMA (HSDPA), CDMA2000 (EV-DO), and TD-SCDMA
Compatible Carriers in USAAT&T*, Sprint*, Verizon*, T-Mobile *
Compatible USB ModemsVisit www.trendnet.com for a list of compatible USB modems
Router/ FirewallNAT, NAPT, and SPI
Static / Dynamic Route (RIP v1/v2)
UPnP, DMZ, Static/Dynamic Route support
DoS (blocking ping, port scan, sync flood)
MAC, port range, service, domain and URL filtering (deny or allow) and ICMP blocking
Power SwitchOn/off
WPS ButtonWi-Fi Protected Setup (WPS) connects to WPS compliant devices
Battery3.7V, 1700mAh Li-ION battery (Compliant with NP120 type batteries)
LED IndicatorPower, Wireless/WPS, USB (3G modem), Ethernet (WAN/LAN)
Power Adapter5V, 2A DC
Power ConsumptionSystem operation: 350mA (max)
Battery charging: 900mA (max)
Dimension (L x W x H)107 x 76 x 21 mm (4.2 x 2.9 x 0.8 in.)
Weight97.38g
TemperatureOperation: 0°~ 45°C (32°F~ 113°F) Storage: -10°~ 70°C (14°F~158 °F)
Humidity Max 95% (non-condensing)
CertificationsCE, FCC
Wireless
Frequency2.400 ~ 2.484GHz
ModulationOFDM, DSSS, BPSK, QPSK, CCK
Data Rate802.11b: up to 11Mbps
802.11g: up to 54Mbps
802.11n: up to 150Mbps
Security64/128-bit WEP, WPA-PSK(TKIP)/WPA2-PSK(AES)
Output Power802.11b: 13dBm @ 11Mbps
802.11g: 11dBm @54Mbps
802.11n: 10dBm @ 150Mbps
Receiving Sensitivity802.11b: -85dBm @ 11Mbps
802.11g: -70dBm @ 54Mbps
802.11n: -68dBm @ 150Mbos
Channels1~11 (FCC), 1~13 (ETSI)
