The 150Mbps Wireless N Home Router delivers the highest level of security with 6x the speed and 3x the coverage of wireless g products. Quickly install the router and use it with TRENDnet wireless n adapters to receive the full benefits of wireless n speed and coverage.
The latest in wireless encryption and a secure firewall protect your valuable data. Router setup is fast and intuitive. Wireless Protected Setup (WPS) integrates other WPS supported wireless adapters at the touch of a button. Seamlessly stream HD media, download files and surf online with wireless n speed.
*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and coverage will vary depending on interference, network traffic, building materials and other conditions.
| Hardware | | Standards | IEEE 802.3 (10Base-T)
IEEE 802.3u (100Base-TX)
IEEE 802.11b
IEEE 802.11g
Based on IEEE 802.11n technology | | WAN | 1 x 10/100Mbps Auto-MDIX WAN port (Internet) | | LAN | 4 x 10/100Mbps Auto-MDIX LAN port | | WPS Button | Enables Wi-Fi Protected Setup (WPS) function | | Connection Type | Dynamic IP, Static (fixed) IP, PPPoE, PPTP, L2TP | | Supported Web Browsers | Internet Explorer 6.0 or above, Firefox, Safari | | Internet Access Control | MAC Address Filter (20 entries), Domain/URL Filter (40 entries), Protocol/IP Filter (20 entries) | | LED Indicators | Power, Status, LAN1 - LAN4, WAN, WLAN | | Power Supply | 5V DC, 1.2A external power adapter | | Power Consumption | 3.5 watts (max) | Dimensions
(LxWxH) | 150 x 110 x 30mm (5.9 x 4.3 x 1.2in) | | Weight | 225g (7.8oz) | | Temperature | Operating: 0° ~ 40°C (32° ~ 104°F)
Storage: -10°C ~ 70°C (-14° ~ 158°F) | | Humidity | 10% ~ 95% max (non-condensing) | | Certifications | CE, FCC | | Wireless | | Frequency | 2.412 ~ 2.484 GHz ISM band | | Antenna | 1 x 2dBi fixed dipole antenna | | Module Technique | 802.11b: CCK (11 and 5.5Mbps), DQPSK (2Mbps), DBPSK (1Mbps)
802.11g: OFDM with BPSK, QPSK and 16/64-QAM
802.11n: BPSK, QPSK, 16QAM, 64QAM with OFDM | | Media Access Protocol | CSMA/CA with ACK | | Data Rate (Auto Fallback) | 802.11b: up to 11Mbps
802.11g: up to 54Mbps
802.11n: up to 150Mbps | | Output Power | 802.11b: 15dBm (typical) @ 11Mbps
802.11g: 15dBm (typical) @ 54Mbps
802.11n: 13dBm (typical) @ 150Mbps | | Receiving Sensitivity | 802.11b: -85dBm (typical) @ 11Mbps
802.11g: -68dBm (typical) @ 54Mbps
802.11n: -62dBm (typical) @ 150Mbps | | Encryption | 64/128-WEP, WPA-PSK/WPA2-PSK, WPA/WPA2-RADIUS | | Channels | 1-11 (FCC), 1-13 (ETSI) |
|
|
