The 54Mbps Wireless G ADSL 2/2+ Modem Router (model TEW-436BRM) is an all-in-one modem and wireless g router.
No need to buy a separate modem and router. This sleek device provides an ADSL 2/2+ modem, wireless g router and 4-port switch, all in a single product.
Quickly install this device to surf the Internet, download files, play games and talk online. Advanced wireless encryption and a double firewall protect your valuable data. Wi-Fi Protected Setup (WPS) allows users to securely synchronize WPS supported wireless peripheral devices at the touch of a button.
| Hardware | | Standards | Compliant with ADSL standards
-?ANSI T1.413 Issue2
-?G.992.1 (G.dmt, Annex A)
-?G.992.2 (G.lite)
Compliant with ADSL2 standard
-?G.992.3 (G.dmt.bis)
Compliant with ADSL2+ standard
-?G.992.5 Annex A
IEEE 802.11b & 802.11g Wireless LAN
IEEE 802.3u 10/100Base TX Fast Ethernet | | Protocol | TCP/IP,NAT, HTTP, DHCP Server/Relay/Client, DDNS, DNS Proxy | | Firewall | NAT Firewall
Stateful Packet Inspection (SPI)
Packet Filtering – IP, MAC Domain, Keyword
Management Access Control for LAN/WLAN | | ATM | VC and LLC Multiplexing
Bridged/Routed Ethernet over ATM (RFC1483/2684)
OAM F4/F5 loop-back
PPP over ATM (RFC2364)
PPP over Ethernet (RFC2516)
ATM TrafficShaping QoS(UBR, CBR, rt-VBR, nrt-VBR) | | Management | Web based Configuration (HTTP
Command Line Interface (CLI) via Telnet
TR-069 Remote Management
SNMP Support
IGMP v1/v2 Support
SW upgrade | | WAN Port (ADSL line Interface) | Complies with ADSL standards
- ANSI T1.413 Issue2
- G.992.1 (G.dmt, Annex A)
- G.992.2 (G.lite)
Complies with ADSL2 standard
- G.992.3 (G.dmt.bis)
Complies with ADSL2+ standard
- G.992.5 Annex A | | LAN Port | 4 x 10/100Mbps Auto-MDIX and Auto-Negotiation RJ-45 Port | | Reset Button | Reset to Factory Default | | On/Off Power Button | Electrical power on/off button | | WPS Button | Wi-Fi Protected Setup (WPS) automated wireless connection push button | | LED | Power,
LAN1~4: Link/ACT
WLAN: Link/ACT
WPS
ADSL
Internet | | Power | 12V DC 1A external?power adapter | | Power Consumption | 6.5 watts (max) | | Dimensions | 195 x 120 x 30 mm (7.6 x 4.7 x 1.2 in) without antenna | | Weight | 351g (12.4 oz) | | Temperature | Operating: 0˚~ 40˚C (32˚~ 104˚F)
Storage: -10˚~ 70˚C (-14˚~ 158˚F) | | Humidity | 10% ~ 90% (non- condensation) | | Certifications | FCC, CE | | Wireless | | Standards | IEEE 802.11b, IEEE 802.11g | | Modulation | DBPSK/DQPSK/CCK/OFDM (BPSK/QPSK/16-QAM/64-QAM) | | Data Rate | 802.11g: up to 54Mbps
802.11b: up to 11Mbps | | Frequency | 2.412 ~ 24.84 GHz | | Antenna | 1 x fixed ?dBi dipole antenna | | Security | 64/128-bits WEP? WPA/WPA2 - PSK, WPA-PSK/WPA2-RADIUS | | Output Power | 802.11b: 14.5dBm (typical)
802.11g: 14dBm (typical) | | Receiving Sensitivity | 54Mbps: Typical - 65dBm @ 10% PER
11Mbps: Typical - 80dBm @ 8% PER | | Channel | 1 ~ 11 (FCC),1 ~ 13 (ETSI) |
|
|
