TRENDnet 54Mbps Wireless G Broadband Router TEW-432BRP Tech Specs



The 54Mbps Wireless G Router offers a complete wireless solution that allows you to share files, an Internet connection, or network resource while protecting your network using enhanced security features. Simply plug your workstations and your broadband modem into the Wireless G router, and configure your broadband connection using its built-in Web Interface.

Use the VirtualServer feature to configure any workstation as a Web Server or FTP server easily, allowing users to view files from the Internet. You can also protect your Wireless LAN using64/128-bit WEP encryption or industry standard WPA-PSK with TKIP or AES algorithms. Increase security by enabling MAC, IP, or Protocol Filtering as well as setting Firewall Rules to limit Internet Access or block malicious intruders from accessing your network.

*Note: Coverage and Speed performance might vary depending on the network environment.


Hardware
Standards
  • Wired: IEEE 802.3 (10Base-T), IEEE 802.3u (100Base-TX), ANSI/IEEE 802.3 Auto Negotiation
  • Wireless: IEEE 802.11b (11Mbps), IEEE 802.11g (54Mbps)
WAN1 x 10/100Mbps Auto-MDIX Port (Internet)
LAN4 x 10/100Mbps Auto-MDIX Port
Connection TypeDynamic IP, Static (Fixed) IP, PPPoE, PPTP, L2TP
Supported Network ProtocolsTCP/IP, NAT, PPPoE/PPTP/L2TP, HTTP, DHCP server/client
LED IndicatorsSystem, WAN, WLAN, LAN, WPS
Dimension (L x W x H)155 x 110 x 30 mm (6 x 4.3 x 1.2 inches)
Weight226g (8 oz.)
Temperature
  • Operation: 0°~ 40°C (32°F~ 104°F)
  • Storage:-10°~ 70°C (14°F~ 158°F)
HumidityMax. 95% (Non-Condensing)
Power Adapter7.5V DC, 1A External Power Adapter
CertificationFCC &CE
Wireless
Frequency2.412 ~ 2.484GHz (Industrial Scientific Medical Band)
Module Technique
  • 802.11b: CCK (11 and 5.5Mbps), DQPSK (2Mbps),DBPSK (1Mbps)
  • 802.11g: OFDM
Antenna1 x 2dBi External Detachable Dipole Antenna (Female Reverse SMA Connector)
Media Access ProtocolCSMA/CA with ACK
Security64/128-bit WEP (HEX/ASCII),802.1x WPA/WPA2, WPA-PSK/WPA2-PSK, MAC Address Filter, Protocol Filter, Domain Filter
Transmit Power802.11b: 15 ± 2dBm; 802.11g: 14 ± 2dBm
Data Rate
  • 802.11b:11Mbps, 5.5Mbps, 2Mbps, and 1Mbps
  • 802.11g: 54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps,12Mbps, 9Mbps and 6Mbps
Receiving Sensitivity
  • 11Mbps8% PER @ -82 dBm (typical)
  • 54Mbps 10% PER @ -65 dBm (typical)
Channels11 Channels (US), 13 Channels (EU)
