TEW-P1UG is a print server that transforms virtually any stand-alone USB printer into a shared network printer. The TEW-P1UG provides an IEEE 802.11g 54Mbps wireless interface for integrating into existing wireless networks. The TEW-P1UG is designed for printers equipped with USB 2.0 compliant printer port and it is an ideal network solution to convert conventional USB printers into a shared resource on the network.
| Hardware | | Standards | - Wired: IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX
- Wireless: IEEE 802.11b/g
| | Printer Interface | USB 2.0, 1.1 Compliant UB Type A port | | LAN Port | 10/100Mbps Auto-MDIX UTP/STP RJ-45 Port | | CPU/ SDRAM / Flash ROM | RDC R2886 150MHz / 2MByte / 512KByte | | Diagnostic LED | Power, Link/Act, WLAN, USB | | Transport Protocol | TCP/IP, SMB, NetBEUI, AppleTalk | | Supported TCP/IP Protocol | BOOTP, SNMP, Telnet, TFTP, FTP, LPD, RARP, DHCP and IPP | | Supported OS | - Windows 7(32/64-bit)/Vista(32/64-bit)/2003 Server/XP(32/64-bit)/2000/98SE
- Netware 5.x NDPS LPR Remote Printing (TCP/IP)
- HP-UX Unix, Sun OS, Solaris, SCO Unix, AIX, Unixware,
- Linux Mac OS 10.1 ~ 10.6
| | Management | Windows Utility or Web-Browser Configuration | | Power | 5V DC 2.5A External Power Adapter | | Dimensions | 115 x 85 x 38mm (4.5 x 3.4 x 1.5in.) | | Weight | 160g (5.6oz.) | | Temperature | - Operating: 0°~50°C (32°~122°F)
- Storage: -25°~55°C (-13°~131°F)
| | Humidity | 10%~90% (non-condensing) | | Certifications | CE, FCC | | Wireless | | Frequency | 2.4 ~ 2.4835GHz (industrial Scientific Medical Band) | | Encryption | 64/128-bit WEP (HEX/ASCII), WPA-PSK(TKIP) | | Antenna | 2dBi Detachable Reverse-SMA (Female) Diversity Antenna | | Data Rate (Auto Fallback) | - 802.11g: up to 54Mbps
- 802.11b: up to 11Mbps
|
|
|
