The 300Mbps Wireless N Gigabit Router with USB Port (model TEW-634GRU) incorporates the latest wireless n technology, Gigabit Ethernet ports and a convenient USB port to create a secure high performance wireless local area network.
Connect USB flash drives, hard drives or printers directly to the router, to share data across your wirelessly local area network.
A robust firewall and advanced wireless encryption protects your network. Wi-Fi Protected Setup (WPS) integrates other WPS devices into your network quickly. Advanced MIMO antenna technology optimizes wireless coverage. Quality of Service (QoS) technology prioritizes gaming, Internet calls and video streaming. An intuitive installation process and remote management capabilities make this product well suited for your most demanding networking needs.
*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and coverage will vary depending on interference, network traffic, building materials and other conditions.
| Hardware | | Standards | Wired: IEEE 802.3/u Fast Ethernet, IEEE 802.3ab Gigabit Ethernet Wireless: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n (draft 2.0), IEEE 802.11e QoS USB: v1.0, 1.1, 2.0 | | WAN | 1 x 10/100Mbps Auto-MDIX port (Internet) | | LAN | 4 x 10/100/1000Mbps Auto-MDIX ports | | WPS Button | Enable Wi-Fi Protected Setup function | | USB | 1 x USB 2.0, 1.1 Compliant USB Type A Port | | Connection Type | Dynamic IP, Static (Fixed) IP, PPPoE, PPTP, L2TP, BigPond | | Internet Access Control | MAC Address Filter, Domain/URL Filter, Protocol/IP Filter | | LED Indicator | Power, LAN1~LAN4, WAN, WLAN, USB | | Power Adapter | 12V DC, 2A external power adapter | | Power Consumption | 7watts (max.) | | Dimension (L x W x H) | 150 x 110 x 30 mm (5.9 x 4.3 x 1.1 inches) | | Weight | 245g (8.6 oz) | | Temperature | Operation: 0°~ 40°C (32°F~ 104°F); Storage: -10°~ 70°C (14°F~158 °F) | | Humidity | 10%~95% RH, no condensation | | Certifications | CE, FCC | | Wireless | | Frequency | 2.412~ 2.484GHz ISM band | | Antenna | 2 x 2dBi detachable dipole antennas | | Media Access Protocol | CSMA/CA with ACK | | Modulation Technique | DBPSK/DQPSK/CCK/OFDM (BPSK/QPSK/16-QAM/64-QAM) | | Data Rate | 802.11b: 11Mbps, 5.5Mbps, 2Mbps, and 1Mbps
802.11g: 54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 9Mbps and 6Mbps
802.11n: up to 300Mbps | | Security | WEP(HEX/ASCII): 64/128-bit WPA(AES/TKIP): WPA/WPA2, WPA-PSK/WPA2-PSK
Enable/Disable broadcast SSID
Protocol filtering
Domain filtering | | QoS | WMM enable/disable feature | | Output Power | 802.11b: 15dBm (typical)
802.11g: 15dBm (typical) 802.11n: 14dBm (typical) | | Receiving Sensitivity | 802.11b: 11Mbps -85dBm (typical) @ 10% per
802.11g: 54Mbps -68dBm (typical) @ 10% per
802.11n: 300Mbps -59dBm (typical) @ 10% per | | Channels | 1~ 11 (FCC), 1~13 (ETSI) |
|
|
